DW-T6 DAWEI 4D COLOR DOPPLER ULTRASOUND SCANNER
BASIC INFO
|
|
Model NO
|
DW-T6
|
Phased Array Probe
|
2.5MHz/3.0MHz/3.5MHz/4.0MHz/H3.0MHz/H4.0MHz,
|
4D Volume Probe
|
2.0MHz/3.0MHz/4.5MHz/6.0MHz/H5.0MHz,
|
Tgc
|
8 Segment Adjustable
|
Dynamic Range
|
20-280dB 20 Level Visual Adjustable
|
Smooth Treatment
|
8, Visible and Adjustable
|
Sound Power
|
5% to 100%, Step 5%, Visible and Adjustable
|
Trademark
|
VSO
|
Trans-Vaginal Probe
|
4.5MHz/6.0MHz/7.0MHz
|
Micro Convex Probe
|
4.5MHz/6.0MHz/7.0MHz
|
Gain
|
0-100, Step 1 Visible Adjustable
|
Image Optimization
|
Visible and Adjustable Over 7
|
False Color
|
12, Visible and Adjustable
|
Edge Enhancement
|
8, Visible and Adjustable
|
Display Depth
|
Greater Than 317mm, Less Than 20mm, Cardiac Probe
|
Transport Package
|
Standard Exporting Packaging
|
- Trolley type all digital color Doppler ultrasonic mainframe
- Ultrasonic host operating system: Window s 8 operating system
- Spectrum pulse Doppler
- Direction energy Doppler
- Real time three synchronization
- Space composite imaging: the requirement is 3 level, visual adjustable
- Organized harmonic imaging technology
- 4B imaging mode
- One key intelligent optimization
- Chinese and English interface, Chinese and English input, optional
- Monitor: 19 inches, high definition LED.
- 10.4 inches touch LED
- Physical clipboard: save the image on the left side of the screen, w hich can be directly saved or deleted
- The system has the function of on-the-spot upgrade
- Presupposition: for different inspection of the viscera, preset the inspection conditions for the best image, reduce the adjustment of the operation, and the commonly used external adjustment and combination regulation
- Support real-time 3D imaging function
- The probe interface is 4
TECHNICAL SPECIFICATIONS:
Probes
Convex array probe 2.5MHz/3.0MHz/3.5MHz/4.0MHz/H4.0MHz /H5.0MHz,
Linear array probe 6.0MHz/7.5MHz/8.5MHz/10.0MHz/H10.0MHz,
Trans-vaginal probe 4.5MHz/6.0MHz/7.0MHz/9.0MHz/H8.0MHz,
Phased array probe 2.5MHz/3.0MHz/3.5MHz/4.0MHz/H3.0MHz/H4.0MHz,
Micro convex probe 4.5MHz/6.0MHz/7.0MHz/9.0MHz/H8.0MHz 4D Volume probe 2.0MHz/3.0MHz/4.5MHz/6.0MHz/H5.0MHz,
Two - Dimensional Imaging Mode
Gain 0-100, step 1 visible adjustable
TGC 8 segment adjustable
Image optimization visible and adjustable over 7 levels
Dynamic range 20-280dB 20 level visual adjustable
False color 12, visible and adjustable
Smooth treatment 8, visible and adjustable
Edge enhancement 8, visible and adjustable
Sound power 5% to 100%, step 5%, visible and adjustable
Display depth greater than 317mm, less than 20mm, cardiac probe 371mm
Maximum focus number 6 focal points, w hich can be moved throughout the whole process.
Scan line density more than 256 visible tunable
Gray scale 0-7 level visible visible and adjustable
Filtering 5 kinds
Scanning range 50%-100%
Frame correlation 0-4 level, visible and adjustable
Color Imaging Mode
Color frequency 8 frequency conversion, visible adjustable
Color deflection equipped with
Color frame correlation 12 levels, visible and adjustable
Color map 7, visible and adjustable
Color reversal adjustable
B/C split screen synchronous display function equipped with
Color baseline 7, visible and adjustable
Color line density adjustable
Spectrum Doppler Mode
Sampling volume angle correction -80 degree to 80 degree adjustable
Sample volume 0.5mm-20mm visually adjustable
Frequency ≥5, visible and adjustable
Baseline 8 adjustable
Smooth 8 files can be adjusted
Display layout 4 visible tunable
False color 7 kinds of adjustable
Speed scale 3-2288cm/s visibility adjustable
Spectrum envelope function real time automatic spectrum envelope, manual spectrum envelope, and other modes. The system automatically analyses and displays various data such as PSV, EDV, RI, PI, S/D, ACC, HR and so on.
Measurement and Analysis Function
General measurement distance, area, angle, time, slope, heart rate, velocity, acceleration, neck hyaline layer, spectrum tracing, resistance index / pulsatility index, etc.
Obstetric measurement: w eight measurement formula more than 8 options
The color and line type of the measuring line can be adjusted at will (including activating the color and completing the color).
The measurement results show that the location and font size can be adjusted according to needs.
Professional softw are package: abdomen, volume, ratio, obstetrics and Gynecology, small organs, carotid artery, Urology, orthopedics, peripheral blood vessels, heart.
Graphic and Text Management System
Host built in ≥128G solid state hard disk to start fast and stable
Movie playback: 1200 frames
Internal file information management system: can record patient number, name, check number, check date and so on, and can be searched and managed by numbering, checking number, name and so on.
The type of report is 16
One key fast report graphic and text management
Interface
USB interface 6
VGA interface 1
RJ-45 interface 1
VIDEO interface 1
Grounding w ire interface 1
Technology, Aafter - Sales Service and Other Requirements
After acceptance, the w arranty is free for tw o years Manufacturer has ISO13485 certification and EU CE certification.
DEMO ALAT
SERTIFIKASI
PACKAGING
